Control Consoles

Clear

Description

#

Magic #

OEM#

Part Description

# Req.

1 ST8  41282733-621 30171622-510 Assembly, control, ST80C, 126 in.

3

1A ST8  41282733-600 30171622-500 Assembly, control, ST80,  90 in.

3

2 ST8  41282733-622 30171622-511 Assembly, control, ST80C,  126 in.

3

2A ST8  41282733-612 30171622-501 Assembly, control, ST80,   90 in.

3

3 ST8  41271792-2 30160681-1 Gauge, torque, ST80/ST80C

1

4 ST8  41282735 30171624 Enclosure, control console

1

5 ST8  41292510 30181409 Guard, control console

1

6 ST8  41282738 30171627 Assembly, tie rod, control

3

7 ST8  41282722-2 30171611-1 Plaque, warning

1

8 ST8  41282491-2 30171380-1 Plaque, warning

1

9 ST8  41282804-2 30171793-1 Plaque, controls

1

* ST8  41282707 30171696 Assembly, console complete, ST80

1

* ST8  41291560 30180459 Assembly, console complete, ST80C

1

*Complete console = control console, torque gauge, cable assembly, warning tags, tubing, guard, all hardware, and fittings.
